172614 PDM-M804A 8-Channel Music Mixer With Amplifier

Gallery:

Price: 1737.00 ₾

Details & Specifications:

Playback options	BT Streaming, USB
Input Connections	6.3 mm jack, RCA, USB, XLR (3-pin)
Output Connections	6.3 mm jack, RCA, XLR (3-pin)
Presets	16
Type of effects	Delay, Echo, Hall, Ping pong delay, Reverb delay, Room
DSP Resolution	24-bit
Output channels	2
Output power:RMS @ 8 Ohm per channel	200W
Frequency Response	10 - 45.000 Hz
THD	<0.01%
Input level:Mic.	1.5mV, 2kohm
Input level:Line	150mV, 100kohm
Signal-to-noise ratio	>112dB
Output level:Master	1V
Power Supply	220-240VAC 50Hz
Dimensions (L x W x H)	350 x 420 x 125mm
Weight (kg)	7.8

172614 PDM-M804A 8-Channel Music Mixer With Amplifier

Home / Audio Equipment / Audio Mixers / 172614 PDM-M804A 8-Channel Music Mixer With Amplifier

Table top design music mixer with built-in amplifier and many attractive features. Features include mute and solo switches on every channel, built-in USB player with digital display and BT receiver to stream music to the mixer during the break. Ideal for live setups and small bands.

- 8 Balanced mono microphone-/line input (Combi XLR/Jack)
- +48V phantom power with individual preamp per channel
- Stereo line input (RCA)
- Multi-FX processor with 16 presets
- Solo switch per channel (PFL)
- On/off switch per channel
- Hi, Mid and Low control for each channel
- Adjustable FX, Pan, Trim per channel
- Stereo balanced main outputs (XLR)
- Separate headphones and stereo rec outputs
- 7-Band equalizer
- Built-in 2x 200W RMS Amplifier
- Built-in USB player with digital display
- BT-receiver for audio streaming
- LED VU meter and Peak LED's
